Working Principle
Operating on the principle of vibration, the feeder uses an electromagnetic vibrator to generate high - frequency oscillations. These vibrations cause the feeding trough to move, pushing materials forward in a step - by - step manner. The control system allows for easy adjustment of vibration intensity and frequency, enabling precise control over the feeding rate.
Key Advantages
Energy - Efficiency
The electromagnetic vibrator ensures low energy consumption while maintaining stable performance, reducing operational costs.
Durability
Constructed from wear - resistant materials like high - manganese steel or stainless steel, the feeder can withstand tough working conditions and abrasive materials.
Easy Maintenance
Its simple structure allows for easy installation, disassembly, and maintenance, minimizing downtime.
Customization Services
Understanding that each customer has unique needs, we provide customized vibrating feeders. Our team designs and manufactures units based on specific material characteristics, production capacity requirements, and site conditions, ensuring the best fit for your production line.
Specification
| Model | Max Feeding Size (mm) | Capacity (tph) |
Motor Power (kW) |
Size of Funnel (mm) |
Machinery Weight(kg) |
| GZD-600 | 200 | 110-150 | 2x0.55 | 1250X630X250 | 379 |
| GZD-700 | 200 | 120-170 | 2x0.55 | 1250X700X250 | 389 |
| GZD-800 | 250 | 160-230 | 2x0.75 | 1500X800X250 | 563 |
| GZD-900 | 250 | 180-250 | 2x0.75 | 1500X900X250 | 613 |
| GZD-1000 | 300 | 270-380 | 2x1.1 | 1750X1000X250 | 762 |
| GZD-1250 | 350 | 400-600 | 2x1.5 | 2000X1250X315 | 1100 |
| GZD-1500 | 500 | 600-870 | 2x2.2 | 2250X1500X300 | 1480 |
| GZD-1600 | 500 | 770-1100 | 2x3 | 2500X1600X315 | 1560 |
| GZD-1800 | 500 | 900-1200 | 2x3 | 2300X1800X375 | 2350 |
| GZD-2000 | 500 | 1000-1400 | 2x3 | 3000X2000X400 | 2710 |
| Model | Max Feed Size (mm) | Capacity (t/h) | Speed of Eccentric Shaft (r/min) | Motor Power (kW) | Size of Funnel (mm) | Overall Dimension (l×w×h) (mm) | Weight (without motor) (kg) |
| ZSW380×95II | 500 | 96-210 | 500-714 | 11 | 3800×960 | 3882×2177×2066 | 4 100 |
| ZSW490×110II | 580 | 160-350 | 500-800 | 15 | 4900×1100 | 4950×2425×2020 | 5 352 |
| ZSW600×130 | 800 | 400-560 | 500-800 | 22/30 | 6000×1300 | 6082×2580×2083 | 7 500 |
| ZSW600×150 | 1000 | 460-615 | 500-800 | 30/37 | 6000×1500 | 6082×2662×1912 | 8 666 |
| ZSW600×180 | 1200 | 600-1000 | 600-850 | 37/45 | 6000×1800 | 6375×2653×2913 | 12 600 |
